Operation – Navigation
990-1599B Smart-UPS® VT 10-30 kVA, 208/220 V and XR Battery Enclosure Operation Manual 13
Logging
From the logging screen on the Main Menu, you can view the 100 most recent UPS log events, and
view the logged details of the events, such as date and time of occurrence, and event number.
• From the Main Menu, select Logging
• Select View Lo g
• Press ESC to return to Main Menu
Example:
The top line indicates date, time and event number.
Lines 2, 3 and 4 are part of the event list. To view the entire list, use UP/DOWN arrows to navigate.
For a detailed description of a particular event, position the arrow, and press ENTER.
View Statistics (submenu under Logging).
From the Logging screen on the Main Menu, you can view the statistics on operation mode changes,
inverter time, duration of battery operation.
• From the Main Menu, select Logging
• Select View Statistics
• Press ESC to return to Main Menu
Control
Status
Setup
Logging
Display
Diags
Help
Main Menu
24-Sep 15:06:48 #15
Mains out of
On Line
Range
===================
Logging Screen (example)
Control
Status
Setup
Logging
Display
Diags
Help
Main Menu
