990-1599B Smart-UPS® VT 10-30 kVA, 208/220 V and XR Battery Enclosure Operation Manual 33
Maintenance Bypass Panel
Operation procedure
The Maintenance Bypass Panel (MBP) can be used to completely isolate the UPS in the event of an
internal UPS fault.
To carry out this procedure, refer to the product-specific manual supplied with the
Maintenance Bypass Panel.
MBP (wall mounted)
MBP (line-up-and-match) with and
without PDU capabilities
