Faucet
Shank
Feed Water
Adaptor
Feed Water
Adaptor
Main Water
Supply
Shut-off
Valve
Sink
Sink
3. Recommend Connection For Flex Line Riser: See Fig.6A. & Fig. 6D. Loosen nut and
separate cold water riser tube from faucet shank. Gently bend riser tube so that the Feed
Water Adapter (Fig 5) fits onto the faucet shank. If your riser tube has no built-in washer, then
fit the cone-shaped washer provided onto the riser tube. Connect the riser tube, the feed water
adapter, and faucet shank together and tighten.
For Solid Copper Riser: See Fig.6B. Follow the same procedure as for flex line. If the copper
riser cannot bend, then it’s best to replace it with a flex line riser. Then fit the feed water adaptor
the same way as described above.
Fig. 6A Fig. 6B
Option Connection Point: See Fig. 6E. The feed water adapter can also be installed between the
riser tube and faucet shank. Loosen nut and separate cold water riser tube from faucet shank.
Gently bend riser tube so that the Feed Water Adapter fits onto the faucet shank. Connect the
riser tube, feed water adapter, and faucet shank together and tighten.
