Apeks WTX-D - Securing the Griplock Cylinder Band

Table of Contents
© 2014 Apeks
NOTE: There is no need to wet the GripLock™ cylinder band prior to securing it to the cylinder.
When properly adjusted, the cylinder band will retain its tension. If adjustment is necessary for
a larger or smaller size cylinder (pre-set for use on an aluminum 80 cf cylinder 7.25 inch / 184
mm), follow the procedure in the section: Adjusting the GripLock™ Cylinder Band.
WARNING: Check that the macro adjustment is set for the appropriate size cylinder.
Failure to do so may result in the cylinder slipping during the course of a dive.
NOTE: Pull the micro adjustment only until it is snug against the cylinder. If the lever is difcult
to close, the micro adjustment is too tight. Loosen the micro adjustment and close the lever to
secure the GripLock™ band to cylinder. If it is difcult to remove the GripLock™ band from the
cylinder, this is an indicator that the micro adjustment was too tight when installed.
Securing the GripLock™ Cylinder Band
1. Make sure the cylinder valve air outlet is facing the back of the BC. Secure the upper GripLock™
band rst to check for proper cylinder placement followed by the lower GripLock™ band. For optimum
cylinder retention, center the GripLock™ buckle assembly on the curve of the cylinder. Connect the
bail into the bail slot of the lever. Hold the lever and pull the GripLock™ patch end of the webbing to
tighten the micro adjustment. Secure the hook and loop webbing on the micro adjustment.
