Attaching the Crotch Strap to WTX Harness
1. Install retainer loop onto the non-looped end of the webbing with loop seam facing inward. Place the
at end of the d-ring on the angled side of the plastic 3-bar slide. Weave the webbing through, starting
from the top side of the plastic 3-bar slide as shown below.
2. Place the WTX harness with the Apeks logo (on the
backpad) face up on a at surface. Feed the webbing
bottom to top through the plastic sewn in crotch strap
retainer on the bottom of the WTX harness.
3. Wrap the webbing around the crotch strap retainer and back through the 3-bar slide and d-ring
(now containing two strands of webbing). Adjust the crotch strap to desired length and tighten when
nished. The extra webbing (tail) can be inserted and secured in the retainer loop.
Loop Seam
Retainer Loop
Crotch Strap
Retainer
To Next Page
