10 | Apogee Element Series Quick Start Guide
Element 88 Product Tour
Inputs 1-4
Combi Jacks XLR Mic/Line
1/4” Hi-Z Instrument
Front Panel
Inputs 5-8
XLR Mic/Line
2 1/4” Stereo
Headphone Outputs
Optical
ADAT/SMUX/SPDIF
BNC
Word Clock
2 Balanced 1/4”
Outputs
PowerThunderbolt™2 Balanced L/R
XLR Outputs
Serial
Number
Rear Panel
Status
LED
