Apogee Element 24 Quick Start Guide

Apogee Element Series Quick Start Guide | 23
5. Select Audio. (A)
6. In the Details drop down (B), select input 1. (C)
7. Check the box for Input Monitoring
and Record Enable. (D)
8. Click Create. (E)
A
B
C
D
E
You should be able to see input
signal in the level meter, and hear it
passing through to the headphone
or speaker output.

Apogee Element 24 Specifications

General

Type	Thunderbolt Audio Interface
Computer Connectivity	Thunderbolt
Form Factor	Desktop
Channels	24
Bit Depth	24-bit
A/D Resolution	24-bit
Analog Inputs	2 x XLR-1/4" combo (mic/line)
Digital Inputs	1 x Optical Toslink (ADAT/SMUX)
Digital Outputs	1 x Optical Toslink (ADAT/SMUX)
Headphones	1 x 1/4"
Sample Rate	192 kHz
Software Compatibility	macOS
Analog Outputs	2 x 1/4" TRS (Main Out)
