Apollo 16 User Manual

Apollo 16 Hardware Manual Hardware Block Diagram 31
Hardware Block Diagram
APOLLO 16 HARDWARE BLOCK DIAGRAM
ANALOG
OUTPUT
CHANNELS
1 - 16
D/A
+4 / -10
SELECT
ANALOG
MONITOR
OUT L/R
PAD
D/A
MON OUT
SHARC®
DSP
DDR2
SHARC®
DSP
DDR2
SHARC®
DSP
DDR2
SHARC®
DSP
DDR2
ARM®
WC TERM
ON/OFF
THUNDERBOLT
OPTION CARD SLOT
1394 INTERFACE
1394B
1394B
PCIe
OUTPUT
VOLUME
XLR MALE
+4 / -10
SELECT
PAD
MADI IN
OPTO
MADI OUT
OPTO
A/D
LINE IN
+4 / -10
SELECT
PAD
DB25
FEMALE
LINE OUT
DB25
FEMALE
BNC
WORD
CLOCK IN
BNC
WORD
CLOCK OUT
75
XLR MALE
AES/EBU
OUTPUT
ANALOG INPUT
CHANNELS
1 - 16
XLR FEMALE
AES/EBU
INPUT
Spartan6
LX75T
FPGA
Word Clock Riser Board
Analog Board
Digital Board
2x4
CONN
2x4
CONN
DC Input Board
1x3
CONN
1x3
CONN
2x10
CONN
2x10
CONN
2x30 CONNECTOR 2x30 CONNECTOR
EEPROM
12VDC IN
1x3
CONN
1x3
CONN
12V
FLASH
2x10 DEBUG CONN
JET PLL
AK4113 AES
RECEIVER
THERM
Front Panel Board
2x17 ARM JTAG
VOLTAGE
REGULATORS
12V
5V
3.3V
1.95V
1.8V 1.2V
1.1V (x4)
REVERSE / OVER
VOLTAGE PROTECT
B - BRIBBON
A-D LINK PCBA
XLR FEMALE
25MHz
