Apollo 3500 - 835;836 CONTROL BOARD PARTS IDENTIFICATION

LED Enable & program
mode push button
Optional Device Inputs
Stop Circuit Jumper
Fire & UL Inputs
Emergency Bypass
Reverse Battery Polarity
Indicators
Optional Device Input
Remote Monitor Outputs
GateLink Connector
Microprocessor
Timer To Close -
Dual Gate Delay -
Current Sensitivity -
Adjustments
Program Switches
835/836 Control Board Parts Identification
Actuator Connector
(Master)
Actuator Connector
(Slave)
Control Board Reset
