Selecting the desired position on the Speed Graph View panel displays
recorded data from the selected time.
NOTE: Searching on the Speed Graph View panel will NOT be available during
playback.
F. Search View Panel
The Search View panel consists of playback and search controls, time-lapse
search table, and event search table.
NOTE: The speed of fast forward is dependent on the USB interface (USB 1.1 or
USB 2.0) and the number of images per second.
You can control the playback speed of images that are currently being played
back by using the control slider. You can control the fast forward
or fast backward playback speed of images that are currently being played
back fast forward or fast backward by using the control slider.
You can enlarge a specific part of the image up to five times using the
control slider. The user can electronically pan and tilt within the
enlarged image by dragging the image using the mouse. Click the left mouse
button on the enlarged image and drag to move its position. You can change
the brightness of the current image using the control slider.
Clicking the icon cancels the brightness changes and resets the image.
NOTE: Zoom in/out and brightness control work only while in the pause mode.
Search Mode: HDP supports two search modes: time-lapse mode and event
mode. The time-lapse search mode searches for recorded data by time and
then plays back images found within the time parameters. The event search
mode searches for event log entries using specific conditions and plays back
