26
Customer Service (704) 841-6000
www.apolloflowcontrols.com
Apl
Flow Controls
INSTALLATION, OPERATION & MAINTENANCE
MANUAL
APPLY TEFLON TAPE TO PIPE
THREADS AND INSTALL
COMPONENTS AS SHOWN.
6"
TYPE 1
BYPASS
LINE
Note: Before attaching bypass line,
remove #2 test cock and nipple
and move them to the opposite
side of the gate valve.
3/4" Male X
1/2" Female Fitting
(2 ea.)
1/2" Tee
1/2" Close Nipple
(~1" Long, 2 ea.)
1/2" X 2"
Long Nipple
(2 ea.)
1/2" 90° Elbow
(2 ea.)
1/2" X 4" Long Nipple
1/2" Ball Valve with Tapped Port
(Note Location of Port)
Meter Nut (2 ea.)
Meter Connector
Water Meter
Rubber Washer (2 ea.)
Adjustment Joint Coupling
1/2" RPLF4A
Reduced Pressure
Backflow Prevente
r
1/2" Ball Valve
without Tapped
Port
1/2" X 5"
Long Nipple
Test Cock
Adjustment Joint Nut
Adjustment Joint O-ring
Adjustment Joint Adapter
BYPASS KITS
