Introduction
Apollo SL30 Installation Manual
5
UNPACKING THE EQUIPMENT
Carefully unpack the equipment. Visually inspect the package contents for any evidence of
shipping damage. Retain all shipping containers and packaging material in case reshipment is
necessary.
PACKAGE CONTENTS
As shipped from the UPS Aviation Technologies factory, the Apollo SL30 package includes
most items necessary for installation other than supplies normally available at the installation
shop, such as wire and cable ties, and required input and output equipment. The standard
items included in the package are listed in Table 1.
Table 1 - Package Contents
Part # Description Qty
430-6040-3xx SL30 NAV/COMM 1
Install kits Part number: 424-2006-300
162-1575 15-pin d-sub connector shell 1
162-1577 37-pin d-sub connector shell 1
162-1008 Right angle coax plug 2
202-0001 Cable tie 2
204-0037 Edge grommet 6"
204-2100 Shoulder bushing 4
221-0400 4-40 x 1/4 SS pan head Phillips machine screw with lock
washer
8
224-0404 4-40 x 1/4 SS flat head Phillips machine screw 4
245-0027 Crimp contact for d-sub, 20 to 24 awg wire 50
310-5181-xx or
310-5197-xx
Mounting frame
NOTE: Only 310-5197-xx is qualified for helicopter use.
1
310-5192-xx Connector mounting plate 1
998-0048 3/32 hex driver 1
Manual kits Part number: 564-0064-300 -4xx
560-0403-xx SL30 User’s Manual 1
560-0404-xx SL30 Installation Manual 1
561-0262-xx SL30 Quick Reference Guide 1
Accessories
115-0007 NAV signal splitter/combiner Optional
S712-0007-012 Internal 3 amp slow blow fuse Optional
Note: Package contents may vary depending on how the unit is ordered.
