Apollo XP95 User Manual

Output Bits
2 Group Mode
1 Alert Tone
0 Evacuate Tone
Interrupt No
Analogue Value
Quiescent 16
Group Address 4
Conict
SNDR and VAD Fail 3
VAD Fail 2
Sounder Fail 1
Input Bits
2 Group Mode
Conrmed
1 Alert Conrmed
0 Evacuate Conrmed
Flag Setting
XP95 Flag Yes
Alarm Flag No
PROTOCOL USAGE
SYNCHRONISATION
It is possible to synchronise the sound and ash
outputs of all Sounder VAD Bases connected
to a loop. Other alarm devices, including the
100dB Sounder, the Integrated Base Sounder,
the Intelligent Base Sounder, the Sounder
Control Unit and the loop-powered VAD, may
also be synchronised.
This method of synchronisation depends on the
design and conguration of the control panel.
Further information should be sought from the
manufacturer of the panel.
MECHANICAL CONSTRUCTION
The Sounder VAD Base is moulded in
polycarbonate and has stainless steel contacts
that accept solid or stranded cables of up to
2.5mm².
TECHNICAL DATA
Operating voltage 17–28V DC
Protocol pulses 5-9V
Current consumption at 24VDC
Quiescent 350µA
Switch-on surge 1.2mA for 1 sec
Activated 14mA
VAD frequency 0.5Hz
IP rating IP21C
Sounder Output (45681-705/706)
High tone setting volume - nominally 75dB (A) to
91dB (A) (Complies with EN54-3)
Low tone setting volume - nominally 55dB(A) to
75dB(A)
Sounder Output (45681-707)
High tone setting volume - nominally 65 to 85dB (A)
(Complies with EN54-3)
Low tone setting volume - nominally 50 to 65dB(A)
DIMENSIONS AND WEIGHT
Part no Description Dimension
& Weight
45681-705 XP95 Sounder VAD
Base with Isolator
(white ash)
115 x
38mm
168g
45681-706 XP95 Slow whoop
Sounder VAD Base
with Isolator (white
ash)
45681-707 XP95 Sounder VAD
Base DIN with
Isolator (white
ash)
45681-292 White Cap 100 x 9mm
20g
45681-293 Red Cap

Apollo XP95 Specifications

General

Color	White
Operating Voltage	17V to 28V DC
Humidity	0% to 95% RH (non-condensing)
Type	Optical Smoke Detector
Protocol	XP95 (Apollo Protocol)
Certification	EN54
