12
Testing the fuse
Battery and Fuse Replacement
Refer to the following figure to replace fuse and the batteries :
2 Caution
˙ Use only a fuse with the
amperage, interrupt, volt-
age, and speed rating
specified.
˙Fuse rating : Fast, 315mA,
1000V, Min Interrupt
Rating 10000A
˙ Replace the batteries as
soon as the low batteries
indicator "=" appears, to
avoid false reading.
˙ When the battery is too low
for reliable operation , the
meter displays “ bAtt”.
The meter will not operate
at all until the battery is
replaced.
˙1.5V x 4 alkaline batteries.
Power-up options :
Press button while turning meter on from OFF position.
Lock button : display of the software version.
Store button : Reset all stored data
˙Remove the test leads before
testing the fuse.
˙If the display reading is FUSE,
the fuse is bad and should be
replaced.
