86
Wheel removal
1. Loosen the wheel nuts.
2. Elevate the vehicle and place a
suitable stand under the frame.
3. Remove the nuts from the wheel.
4. Remove the wheel.
1. Nut (x4)
Wheel installation
1
、
Install the wheel and the nuts.
NOTE:
● The arrow mark on the tire must
point toward the rotating direction
of the wheel.
● Tapered nuts are used for both the
front and rear wheels. Install the
nut with its tapered side towards
the wheel.
1. Arrow mark
