Line Voltage Derating
The capability of the HV charger to deliver energy to the load (storage capacitors) reduces with
reduced line voltage as the following tables apply.
240 V Models
Line Voltage
Charge Rate
180 VAC
1250 J/second
200 VAC
1400 J/second
210 VAC
>1500 J/second
115 V Models
Line Voltage
Charge Rate
100 - 115 VAC
1300 J/second
116 – 130 VAC
>1500 J/second
You may notice that the low line voltages above are below those specified in the rear of this
manual under „specifications‟ The above tables denote the ability of the charger to perform under
certain line voltage conditions, and not the complete system. We do not recommend operating the
CSP-P units below the minimum voltages listed in the specification section of this manual.
