APRILIA CAPONORD User Manual

04_21
Headlight adjustment (04_21, 04_22, 04_23, 04_24, 04_25,
04_26)
NOTE
IN COMPLIANCE WITH LOCAL LEGISLATION, SPECIFIC PROCEDURES MUST
BE FOLLOWED WHEN ALIGNING THE LIGHTS.
04_22
To quickly and easily check the alignment of the front light, place the vehicle on a level
surface 10 m (32.8 ft) away from a vertical wall. Turn on the dipped beam light, sit on
the vehicle and check that the light beam projected onto the wall is a little below the
level of the headlight (about 9/10 of the total height).
To carry out vertical adjustment of the light beam:
•
Rest the vehicle on its stand.
•
Remove the horn fixing screw (1).
04_23
•
Remove the horn (2) after having disconnected the connectors
131
4 Maintenance
