Refitting the driven pulley
- Fit the driving belt in driven pulley with the specific
tool.
- Fit the assembled unit on the shaft.
See also
Refitting the
clutch
Drive-belt
- Make sure the driving belt is not damaged and does not show signs of abnormal wear.
- Replace according to the scheduled maintenance table.
Removing the driving pulley
- Lock the driving pulley using the specific tool.
Specific tooling
020660Y Driving pulley check ring
- Undo, remove the fixing screw and collect the washer.
- Extract the gear from the seat removing it from
the control bushing (remove completely after ex-
tracting the pulley).
MSS Mana GT ABS Engine
ENG - 249
