RS 50
ch. 5
5-3
5
Release 00 2001-03
Cooling system
WARNING
Plug the ends of the hoses, to prevent foreign
bodies from getting into them.
NOTE Replace the rubber pads (9) if worn.
CAUTION
Any foreign material, dirt etc. that is stuck to the
radiator fins must be removed with a blast of
compressed air.
Any bent fins must be straightened using a small
flat-bladed screwdriver.
Replace the hoses if they show any signs of
abrasion, checking or cracking.
Wash out the inside of the radiator thoroughly
before refitting it, using clean water only.
To refit, follow the removal steps in reverse order,
replacing the hose clamps.
REMOVING THE FILLER CAP
Read carefully (PRECAUTIONS AND GENERAL
INFORMATION) and (COOLANT).
Remove the l.h. side fairing (REMOVING THE SIDE
FAIRINGS).
Remove the dashboard closing cowl (2) retainer
screw (1).
Loosen and remove the clamp (3) from the filler hose
(4), then disconnect the hose.
Unscrew the filler cap (5), remove the screw (6) and
withdraw the filler (7).
Plug the hose covers to prevent foreign material
from entering.
NOTE Replace the filler hose (4) with a new one if
damaged.
To refit, follow the removal steps in reverse order.
WARNING
9
9
1
2
1
5
6
7
3
4
