APRILIA RSV4 RR User Manual

REAR EXHAUST MANIFOLDS
•
Remove the catalytic converter.
•
Remove the left rider footpeg.
•
Unscrew and remove the four nuts fas-
tening the rear exhaust manifolds and
retrieve the washers.
•
Remove both rear exhaust manifolds.
Butterfly valve in exhaust
To check correct operation and calibration of the exhaust valve, see electrical system section.
REMOVING THE EXHAUST THROTTLE VALVE
•
Remove the fairing lug.
•
Disconnect the connector from the
valve actuator motor.
See also
Lower cowl
Chassis RSV4 RR/RF
CHAS - 478

APRILIA RSV4 RR Specifications

General

Displacement	999.6 cc
Compression Ratio	13.6:1
Max Power	201 HP (148 kW) @ 13, 000 rpm
Transmission	6-speed cassette type gearbox
Front Tire	120/70 ZR 17
Rear Tire	200/55 ZR 17
Engine Type	65° V4
Bore x Stroke	52.3 mm
Fuel System	Electronic fuel injection with 4 Marelli 48-mm throttle bodies
Max Torque	115 Nm @ 10, 500 rpm
Frame	Aluminium dual beam chassis with pressed and cast sheet elements
Front Suspension	43 mm
Rear Suspension	Sachs monoshock with adjustable compression, rebound and preload
Front Brakes	Dual 320 mm discs with Brembo M4.32 monobloc radial calipers
Rear Brakes	220 mm disc, Brembo caliper
Fuel Capacity	18.5 liters
Dry Weight	180 kg
Seat Height	845 mm
