TECHNICAL SPECIFICATIONS
AEON Active Studio Monitor
Field Monitor
Near-medium
Type
Active – two power amplifiers:
- Tweeter p.a.: monolithic integrated circuit TDA7294
- Woofer p.a. operates on 2SA1943/2SC5200
System
Two-way
Crossover Frequency
1.5 kHz (slope: 24 dB/octave.)
Dimensions: Height × Width × Depth
42 cm × 27 cm × 36 cm/ 16.5’’ x 10.5’’ x 14’’
Free Field Frequency Response
± 2 dB: 30 Hz ÷ 30 kHz
SPL in Free Field @ 1m
RMS: 108 dB
Peak: 116 dB
Weight
18 kg / 39.6 lbs.
Loudspeakers
Bass/Mid-Range Loudspeaker
φ 22 cm (8 2/3’’)
Diaphragm: cellulose, surround: rubber
Magnetically shielded
Tweeter Loudspeaker
φ 2.5 cm (1”) in two versions:
- Fabric dome
- Titanium dome
Magnetically shielded
Amplifiers
Bass/Mid-Range Power Amplifier
150 W RMS @ 4 Ω
Tweeter Power Amplifier
70 W RMS @ 6 Ω
THD Distortions
0.005 % – P
O
= 5 W, f = 1 kHz
0.1 % max – P
O
= 0.1 up to 50 W, f = 20 Hz up to 20
kHz
Signal to Noise Ratio
103.5 dB – weighted by A curve
101 dB – in band of 20 Hz up to 20 kHz
Input Voltage Level for 100 dB SPL In Free Field @ 1m
0 dBu (i.e. 0.775 V) – calibrated regulators in 0 dBu, 0
dB positions
Calibrated Controls
Input Sensitivity Switch
30dBu, 22dBu, 15dBu, 9dBu, 4dBu, 0dBu, -3dBu,
-10dBV
Bass Controller Level Switch
-15dB, -12dB, -9dB, -6dB, -3dB, 0dB, 3dB, 6dB
