APsmart RSD-D - TECHNICAL DATA-RSD-D

User Manual
12
TECHNICAL DATA—RSD-D
Model
RSD-D
Input Data (DC)
Input Operating Voltage Range
8-80V Per Channel
Maximum Cont. Input Current (Imax)
15A Per Channel
Output Data (DC)
Output Operating Voltage Range
16-160V
Maximum Output Current
15A
Maximum System Voltage
1000V/1500V
Mechanical Data
Operating Ambient Temperature Range
-40
o
F to +167
o
F (-40 °C to + 75 °C)
Dimensions (without cable & connectors)
5.5" x 2" x 0.8"(140 mm x 50.6 mm x 20 mm)
Cable Length
Input 500mm/Output 2200mm
Cable Cross Section Size
TUV:4mm²/UL:12AWG
Connector
MC4 or Customize
Enclosure Rating
NEMA Type 6P/IP68
Over Temperature Protection
Yes
Features & Compliance
Communication
PLC
Safety Compliance
NEC 2017 & 2020 (690.12); UL1741; CSA C22.2 No. 330-
17; IEC/EN62109-1
EMC Compliance
FCC Part15; ICES-003
