APsmart RSD-D - TECHNICAL DATA-TRANSMITTER-PLC

User Manual
13
TECHNICAL DATA—TRANSMITTER-PLC
Model
Main electrical data
Transmitter-PLC
Main electrical data
Input Voltage
12VDC
Input Current
0.8A
Communication
PLC
Power Supply
Residential（optional）
85-264VAC Input, 12VDC Output, 90 mm x 17.5 mm x 58.4 mm
Commercial
（
optional
）
180-550VAC Input, 12VDC Output, 125.2 mm x 32 mm x 102 mm
Core data 29mm Core 11mm Core
Max. Current 150A Per core 75A Per core
Max. System Voltage 1500VDC
Internal Opening for Wires/Outside Dimensions ~29mm/65mm ~11mm/35mm
Max. Supported PV Modules per String 30 modules
30 modules
30 modules
Number Of Strings Per Core
DC Cable Diameter(without connector)
Φ
5.9mm
Φ
6.35mm
Φ
7mm
Φ
8.6mm
29mm Core
≤15
≤15
≤14
≤10
11mm Core
≤6
≤5
≤4
≤2
Environmental
Temperature
-40℃～+100℃
Structure data
Dimensions (W x H x D)
90 mm x 35 mm x 40 mm
Enclosure Environmental Rating
IP30
Features & Compliance
Safety Compliance
NEC 2017 & 2020 (690.12); UL1741; CSA C22.2 No. 330-17
EMC Compliance
FCC Part15; ICES-003
