aptos MAC DTU - Power Adapter Specifications; Mechanical and Compliance Data

17
Adapter input voltage/frequency
100 to 240 V AC / 50 or 60Hz
Adapter output voltage/current
5V / 2A
Power consumption
2.5W (typical), 5W (maximum)
Mechanical Data
Ambient temperature (℃)
-20°C to 55°C
Dimensions (W×H×D)
200mm×101mm×29mm
Weight
0.20 kg
Mounting system
Wall mounting / Desktop mounting
Features
Compliance
FCC 15B, FCC 15C, EN60950-1, EN61000-3-2,
EN61000-3-3, EN301489, EN300328, EN300440, RCM
*1 If the DTU installation location is inside the metal box or under the metal/concrete roof, extended antenna will
be suggested.
*2 Depending on the installation environment, please refer to user manual for more details.
© 2021 Aptos Solar Technology, LLC. All rights reserved.
MAC
TM
DTU
