Aputure amaran T4c - DMX Control; DMX Connection; DMX Interface Schematic

- 11 -
3. DMX Control
3.1 Connecting Type-c to DMX adapter to the lighting fixture.
3.2 Connect a standard DMX controller
3.3 The DMX interface schematic.
Connecting DMX
to only one light
DMX512
OUTPUT
DMX512
Daisy chaining multiple
lights using DMX
DMX512
OUTPUT
DMX512
* Type-c to DMX adapter is not standard
Signal Common
Data 2+ (Optional Secondary
Data Link)
Data 2- (Optional Secondary
Data Link)
Signal Common
Data 2+ (Optional Secondary
Data Link)
Data 2- (Optional Secondary
Data Link)
1
1
2
3
4
5
2
3
4
5
Data 1+ (Primary Data Link)
Data 1- (Primary Data Link)
1
2
3
4
5
1
2
3
4
5
1
2
3
4
5
Data 1+ (Primary Data Link)
Data 1- (Primary Data Link)
1
2
3
4
5
