15 | CIRCUIT DIAGRAM
• MINI TOUCH
• FLEXIBLE TOUCH
Water tank
Sensor
Sensor
Pump
TDS
sensor
Flushing valve
Composite
RO Membrane
Ater-lter
Filtered
Water
UV
Pump
Heating coil
Temperature
sensor
Water
outlet
Inlet valve
Angle Valve
Drain clamp
Water level gauge
Prelter
TDS
sensor
Flushing Valve
Composite
RO Membrane
After-lter
Filtered
water
UV
Pump
Heating coil
Temperature
sensor
Water
outlet
Water level gauge
