Quartz Digital exposed with adjustable head installation instructions Page 11
Carefully slide the rail end covers onto the
fixing brackets flush with the finished wall
surface and click the sides firmly into position.
17
Slide the ceiling plate up to the ceiling to cover
the entry hole.
18
The ceiling plate cannot be sited against an
uneven surface. If there is coving or an
alternative obstruction, please ensure the entry
hole is neat and unobtrusive; otherwise the
inner tube could be visible within the showering area.
If the ceiling height is over 2.4m (8ft), a Digital riser rail extension kit will be
required. Contact our Customer Service Department to purchase a riser rail
extension kit (part no: 223217).
!
