Adjustable Head
To avoid water dripping from the shower head after use, we advise to tilt the head back
to allow residual water to drain out.
The above recommendation applies to both adjustable and fixed shower heads.
4. Eco3. Outer
2. Middle1. Inner
4
3
1
2
The angle of the fixed shower head can be
adjusted. The shower head is mounted on
a multi directional ball joint to allow for
minor angular adjustment in any direction
by carefully holding the shower head and
moving the head to the desired angle.
N.B. Do not force the angle of the head
beyond its natural stopping point.
Fixed Head
1. Rotate the spray plate lever clockwise or anti-
clockwise to select the desired spray pattern.
When the lever is in position 4, the water saving
‘Eco’ mode is selected. This provides the same spray
pattern as position 3, but, depending on which water
system the product is fitted to, oers up to 25%
water saving.
2. To select the preferred height for the shower head,
press the button to allow the handset holder to
move up or down the rail.
3. Angular adjustment is made by carefully but firmly
pulling forwards or pushing back the shower head
against the ratchet in the holder.
Removing the shower head: Depress the anti-swivel
locking button on the handset and unscrew the hose.
1. Push the waste cover to engage the plug fitting.
2. Push the waste cover again to disengage the plug.
Bath Overflow Filler
Do not leave the bath filler running
unattended. Although the overflow will
remove excess water once the bath is
overfilled, this may not be sucient
to prevent the bath from overflowing
(depending on system conditions).
10 11
