Infinity Owner's Manual & Installation Guide
ILLUSTRATION NO. PART # DESCRIPTION
1A. 8131BOX CNTRL;CHROMATH;SLAVE CNFG.;TO6
1B. 8020LIGHTS CHROMATHERAPY;20LEDS BULB;RND CLR
--- LENS REMOVAL TOOL
--- 20LEDS CHROMATHERAPY BULB
2A. 8186ASSYxx FULL SIZE DIRECTIONAL JET
2B. 8186VJTB V-JET BODY
8186BDY 90 DEGREE JET BODY
8186WFTG WALL FITTING
3A. 1120xx 150GPM SUCTION COVER
3B. 1122NUT 150GPM SUCTION NUT
3C. 1124RING 150GPM SUCTION COMP RING
3D. 1121ELBOW 150GPM SUCTION ELBOW
1119SLIP SUCTION SAFETY VALVE
4A. 8180ROTxx ROTATIONAL SWIRL JET
4B. 8180JTB ROTATIONAL SWIRL JET BODY
4C. 8180NUT JET NUT
5A. 8182DIRWH PRESSURE PLUS JET INTERNAL
5B. 8182JTB PRESSURE PLUS JET BODY
5C. 8182NUT PRESSURE PLUS JET NUT
6A. 9250MAGNET PILLOW MAGNET;ROUND;3/4”X1/8”
6B. 9250PILLWH MAGNETIC PILLOW; WHITE
6C. 9250PILLBK MAGNETIC PILLOW;BLACK
7A. 8169KEYPAD KEYPAD;BDL;INFINITY;RECT
7B 8170KEYPAD KEYPAD;BDL;INFINITY;OVAL
8A. 8511FTG 3/4” TEE
8B. 8514FTG 3.4” ST 90 EL
9A. 8504FTG 3/4” WYE 22.5 DEG
10A. 1092 3/8” PVC AIR TUBING
10B. 8038TEE 3/8” BARB TEE; AIR
11A.
8012CVALVE 14MM ILLUSION CHECK VALVE
11B. --- 14MM ILLUSION JET STOPPER
11C. --- 14MM ILLUSION JET BODY
11D. --- 14MM ILLUSION WASHER
11E. 8012TEE ILLUSION TEE
11F. 8012ELBOW ILLUSION ELBOW
12A. 8504SEQ 4 PORT AIR SEQUENCER MODULE KIT
12B. 1104BLOWER BLOWER;750W;HEATER;120V;W/NEMA
12C. 8173MANIFOLD AIR MANIFOLD;1.5” / 3.8” SPG-4
12D. 1093 3FT INTAKE HOSE W/ CLAMPS
13A. 8135BOX CONTROL BOX;EVO 2; SOFTWARE AQ01
13B. --- AIR SEQUENCER COMMUNICATION CABLE
14A. 8095HEATER 1.5 KW MAINTENENCE HEATER
14B. --- 2PC. HEATER SPLIT NUT
14C. 8515FTG 2” X 1.5” ADAPTER/ PUMP UNION
14D. 8108MOTOR 1.75HP /120V PUMP
14E --- GASKET / O-RING
14F. --- 1.5” X 1” TAILPIECE
INFINITY SERIES
REPLACEMENT PARTS LIST
* To indicate color, replace “XX” with “WH” for White, “BO” for Bone, “BK” for Black, “ST” for Sterling Silver, “BI” for Biscuit, “CR” for Chrome,
“BR” for Brass, “BN” for Satin Nickel
