The PL7004/Kit includes the equipment listed below. The FI7000 is housed in a 19” wide by
3.5” (2U) high instrument case with a 1.75 (1U) high blank panel. Please see individual
product specification sheets for details.
Units shown not to scale.
Model PL7004/Kit Equipment List:
Model PL7004 Probe with carrying case and Calibration Report from an A2LA-
accredited lab
Model FI7000 Probe Interface
Model FC7010 Fiber Optic Cable set for FL7000 Series probes, 10 meters.
Model MA7000 Fiber Optic Mating Adapter Set
NOTE: FM7004A is recommended for local monitoring and control.
Features
Specifications
PL7004/Kit
Peak Measuring Electric
Field Probe Kit for
Pulsed Fields
800MHz—3.6GHz
80—800 V/m
User–selectable X,
Y, Z Axes
AR RF/Microwave
Instrumentation
160 School House Rd
Souderton, PA 18964
215-723-8181
For an applications engi-
neer call:800.933.8181
www.arworld.us
To order AR Products, call 215.723.8181. For an applications engineer call:800.933.8181. Direct to Service call: 215.723.0275 or
email: service@arworld.us For Faxing Orders:866.859.0582 (Orders Only Please) info@arworld.us
Approved for public release by AR RF/Microwave Instrumentation 102914
Model Description
PL7004/Kit FI7000 Housed in 2U Instrument Case
PL7004/Kit M1 Rack Mount (Instrument Case removed)
