4.29) View the side with the spigots of the
plastic spacer locators tub rail
(668PE051R/L) and cut off spigots as
marked on underside of spacer.
“M” (for middle position)
Cut all other pins off, other than pins
marked “M” for the middle spacer
position.
“R” (rear position)
Cut all other pins off, other than pins
marked “R” for the rear spacer position.
Ensure pins are cut below the side
profile height of the spacers so they sit
flat on top of tub.
