ARB AIRLOCKER RD147 - Itemized Parts List

7 Parts List
42
7.3 Itemized Parts List
(See exploded diagram figure 25.)
ITEM #
QTY
DESCRIPTION
PART #
NOTES
1
1
SEAL HOUSING O-RINGS (PK OF 2)
160207-2
1
2
1
SEAL HOUSING KIT
081803SP
3
2
SHIM KIT
SHK009
*
2
MASTER SHIM
150352
4
1
BONDED SEAL
160703SP
5
1
CLUTCH GEAR & WAVESPRING KIT
050904SP
6
1
SPIDER BLOCK
070201SP
7
1
LONG CROSS SHAFT
060204SP
8
1
SIDE GEAR
SEE NOTE
4
9
1
COUNTERSUNK SCREW (PK OF 2)
200213SP
10
1
RETAINING PIN SET (PK OF 4)
120601SP
11
2
TAPERED ROLLER BEARING
160101
2
12
1
FLANGE CAP KIT
027305SP
13
1
WAVESPRING
150704SP
14
1
SPLINED SIDE GEAR
SEE NOTE
4
15
2
SHORT CROSS SHAFT
060403SP
16
4
PINION GEAR
SEE NOTE
4
17
4
PINION THRUST WASHER
SEE NOTE
5
18
2
SIDE GEAR THRUST WASHER
SEE NOTE
5
19
1
DIFFERENTIAL CASE
013005SP
*
1
BULKHEAD FITTING KIT (BANJO TYPE)
170114
6
*
1
AIR LINE (6mm DIA X 6m LONG)
170314SP
6
*
1
SOLENOID VALVE (12V)
180103
*
1
SWITCH|FR OR RR LOCKER
180225
*
1
CABLE TIE (PK OF 25)
180305
*
1
OPERATING & SERVICE MANUAL
210200
*
1
INSTALLATION GUIDE
2102147
*
Not illustrated in exploded view
NOTES
1
For replacement O-rings use only BS136 Viton 75.
2
For replacement bearing use Timken part # LM104949 / LM104912.
3
Newer OEM Dana 44 ring and pinion sets may use 3/8”, 7/16” or 1/2” bolts. The flange holes
of the Air Locker may need to be drilled or reamed from Ø3/8” to Ø7/16” or Ø1/2” to suit.
4
Available only as complete 6 gear set # 728H031 Suitable for use with ABS tone ring.
35 spline Dana 44 is a performance upgrade requiring aftermarket axle shafts.
5
Available only as complete thrust washer kit #730H01
6
All diffs produced before serial #17070001 came with 5mm air connection system.
For information contact ARB.
Part No. 2102147
Revision 27/10/2020
Copyright © 2016 by ARB Corporation Limited
