2 Safe Air Compressor Operation
10
2.4 Air Powered Tools
In addition to tyre inflation the ARB CKMPT12 is suitable for operating most air
powered tools, some of which are shown below.
• With the compressor connected and switched on as described in Section
2.2, connect the air tool to the air hose coupling by inserting it into the
coupling and simply pressing inward until the coupling sleeve clicks
forward. The sleeve of the coupling does not need to be pulled back by
hand at all.
• The ARB CKMTP12 will continuously run air tools which require up to
85LPM [3CFM] @ 600kPa [90PSI]. For maximum power output from your
air tool allow the compressor to fill the air tank to maximum pressure before
operating and in between uses.
