2.5 Keeping The Carry Case Organised
The ARB CKMTP12 packs a lot of gear into a purpose built carry case.
The compressor carry case has been designed with designated storage
compartments for the accessories to help keep things organised. The wiring
loom has also been configured with the black wire longer than the red to allow
it to pack away as neatly as possible. The picture below shows the intended
layout for organising the carry case in the most effective way.
Keep the inflation
accessories, spare
fuses, etc. in this pocket
Wiring loom is coiled
in an counter-
clockwise direction
Coiled u
the air hose
ir blow
un
Black alligator clamp
has a longer wire and
fits next to air tank
Fuse holders fit
neatly in this space
Red alligator clamp
fits next to air tank
