1 Introduction
4
1.3 Specifications Of The CKMTP12 Portable Compressor
GENERAL SPECS METRIC IMPERIAL
SUPPLY VOLTAGE 12 Volts DC 12 Volts DC
MAX CURRENT DRAW (each motor) 34.3 Amps @ 1030 kPa 34.3 Amps @ 150 PSI
MAX CURRENT DRAW (total) 68.6 Amps @ 1030 kPa 68.6 Amps @ 150 PSI
FUSE RATING (each motor) 40 Amps 40 Amps
RELAY RATING (each motor) 40 Amps 40 Amps
WEIGHT (total kit) 15 kgs 33 lbs
DIMENSIONS -LENGTH 478 mm 18.8 inches
-WIDTH 355 mm 14.0 inches
-HEIGHT 186 mm 7.3 inches
DUTY CYCLE @ 22°C [72°F] 100 % 60 mins. per hour
PRESSURE SWITCH CLOSED < 930 kPa < 135 PSI
PRESSURE SWITCH OPEN > 1030 kPa > 150 PSI
SAFETY VALVE PRESSURE > 1240 kPa > 180 PSI
MOTOR THERMAL CUT-OUT 115 degrees C 239 degrees F
MAX. AMBIENT TEMPERATURE 100 degrees C 212 degrees F
SPECS @ NO LOAD METRIC @ 0 kPa IMPERIAL @ 0 PSI
CURRENT DRAW 28.4 Amps 28.4 Amps
AIR FLOW RATE 174.4 L/min. 6.16 CFM
SPECS @ TYRE PRESSURE METRIC @ 200 kPa IMPERIAL @ 29 PSI
CURRENT DRAW 50.4 Amps 50.4 Amps
AIR FLOW RATE 131.8 L/min. 4.68 CFM
NOTE:
The specifications above were recorded under laboratory
conditions at 22°C [72°F].
EXTERNAL CONNECTIONS SPECS
AIR INTAKE THREADS (female) 1/4-18 NPSC (parallel pipe thread)
AIR FILTER THREAD (male) 1/4-18 NPT (tapered pipe thread)
PRESSURE SWITCH THREAD 1/4-18 NPT (tapered pipe thread)
SAFETY VALVE PORT THREAD 1/8 BSPP (parallel pipe thread)
MANIFOLD OUTLET THREAD 1/4-18 NPT (tapered pipe thread)
STAINLESS BRAIDED HOSES JIC-4 [AN-4]
AIR COUPLING FITTING TYPE ‘US Industrial Standard’
(international equivalent standards) ISO 6150 B
Rectus series 23/24/1400
Tema series 1400
Legris series 23
DYNAQUIP D3
CEJN 310
US.MIL.C 4109
Norma / AFNOR: NF.E49.053
Parker series 30-¼” and 20-¼”
Aignep 220
Hansen series 3000
Norgren series 237
Gromelle series 600
WARRANTY
This ARB Air Compressor is designed to provide many years of trouble free recreational use, and is
warranted to be free from manufacturing defects for two (2) years from the date of purchase.
