4 Parts List
16
CKMTP12
Portable Compressor Kit
Specs:
ITEM # QTY DESCRIPTION PART # NOTES
01 1 CARRY CASE 270104
Voltage
12 V DC
02 1 HOSE ASSEMBLY, TANK INPUT 170305
Current Draw
No-Load
28.4A
03 1 SCREW (COUNTERSUNK M6 x 16) 200715
Load
50.4A
04 1 TWIN COMPRESSOR MOUNT ASSEMBLY 320108
Air Flow
174.4L/min @ 0kPa [6.16CFM @ 0psi]
05 2 BOLT (M6 x 60mm) 200703
131.8L/min @ 200kPa [4.68CFM @ 29psi]
06 2 FLAT WASHER 6151046
Total Weight
15kg [33lbs]
07 2 O-RING (BS010V75) 160242
Size
186mm x 478mm x 355mm (H,L,W)
08 1 MANIFOLD CAP (1/4” NPT) 320214
[7.3” x 18.8” x 14”]
09 1 ADAPTER (1/4" NPT TO JIC-4) 170631
Outlet
Hose coupling, US std female
10 2 COMPRESSOR ASSEMBLY CKM01
Pressure Switch
Open
1030kPa [150psi]
11 2 AIR FILTER BASE 320501B 1
Closed
930kPa [135psi]
12 2 AIR FILTER ELEMENT (DISK TYPE) 290503 1
Safety Valve
Open @ > ~1240kPa [180 PSI]
13 2 AIR FILTER COVER 320501A 1
14 8 BOLT (M6 x 12mm) 200702
15 2 AIR FILTER FLANGE (1/4” NPT) 320212
Notes:
16 2 O-RING (BS029N70) 160250 2
17 3 O-RING (BS031N70) 160241
18 1 COUPLER MANIFOLD 320227
19 1
PRESSURE SWITCH (1/4” NPT) CO35
1 AIR FILTER BASE (11) & COVER (13) available
20 1
COVER ASSEMBLY, CKMTP 320109
3
only in AIR FILTER ASSY #320501 which also
21 1 SWITCH BRACKET, CKMTP 320230
includes the element.
22 1 HOSE COUPLING (US STD FEMALE) 170403
23 1 SWITCH (12V) 180209
2 Complete set of CKM series O-ring seals is available
1 SWITCH COVER (ARB COMPRESSOR) 180212
as O-ring Service Kit #320301. (Order two for CKMTP12)
24 1 CARRY CASE POCKET 270105
25 1 HOSE ASSEMBLY, TANK OUTPUT 170306
3 Cover assembly is preassembled with the relays, fan and
26 1 AIR TANK 171501
wiring loom.
*
1 INFLATION ACCESSORY KIT (US STD) 171303
*
1 HOSE ASSEMBLY (US STD) 171301
*
1 AIR BLOW GUN 171309
*
1 WIRING LOOM (CKMP12 SUPPLY) 180412
*
1 WIRING LOOM (CKMP12 SWITCH) 180413
*
Not illustrated in exploded view.
