ARC 160 - Dimension; Disassembly and Reassembly

20
4-8 Dimension
Fig. 4-8-1: Dimension Table. 4-8-1: Dimension
4-9 Disassembly and reassembly
4-9-1 Disassembly and reassembly of unit
Fig. 4-9-1: Disassemble and reassembly of unit
NO.
Item
Unit(mm)
Unit(inches)
1
length
389
15.3
2
Width
155
6.1
3
Height
300
11.8
