Arcam AVR550 Custom Installation Notes

27
Function RC5 Code
[system-command]
RC5 Code
(Data1 - Data2)
Decimal Hexadecimal
Zone 2 Power Off 23-124 0x17 - 0x7C
Zone 2 Vol+ 23-1 0x17 - 0x01
Zone 2 Vol- 23-2 0x17 - 0x02
Zone 2 Mute 23-3 0x17 - 0x03
Zone 2 Mute On 23-4 0x17 - 0x04
Zone 2 Mute Off 23-5 0x17 - 0x05
Zone 2 CD 23-6 0x17 - 0x06
Zone 2 BD 23-7 0x17 - 0x07
Zone 2 STB 23-8 0x17 - 0x08
Zone 2 AV 23-9 0x17 - 0x09
Zone 2 Game 23-11 0x17 - 0x0B
Zone 2 Aux 23-13 0x17 - 0x0D
Zone 2 PVR 23-15 0x17 - 0x0F
Zone 2 FM 23-14 0x17 - 0x0E
Zone 2 DAB 23-16 0x17 - 0x10
Zone 2 USB 23-18 0x17 - 0x12
Zone 2 NET 23-19 0x17 - 0x13
Zone 2 SAT 23-20 0x17 - 0x14
Zone 2 VCR 23-21 0x17 - 0x15
Select HDMI Out 1 16-73 0x10 - 0x49
Select HDMI Out 2 16-74 0x10 - 0x4A
Select HDMI Out 1 & 2 16-75 0x10 - 0x4B

Arcam AVR550 Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	110 dB
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	7
Ethernet LAN (RJ-45) ports	1
Number of HDMI outputs	3
AirPlay	No
Audio decoders	DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD Master Audio
Audio Return Channel (ARC)	Yes
Apple docking compatibility	Not supported
Power consumption (standby)	0.5 W
Power consumption (typical)	1500 W
Supported radio bands	DAB, DAB+, FM
Internet radio services supported	Spotify
12V trigger ports quantity	2
Speakers connectivity type	-
Package weight	18800 g

Weight and Dimensions

Depth	425 mm
Width	433 mm
Height	171 mm
Weight	15500 g
