Remote Control
Note: Incorrect use of batteries can have hazardous results. Do not mix old and new batteries
together. Do not use non-identical batteries together. Although they may look similar, different
batteries may have different voltages. Ensure the batteries are inserted in the correct direction.
Remove batteries from equipment that is not going to be used for a month or more. When disposing
of used batteries, please comply with governmental or local regulations that apply in your country or
area.
Display Control
Press the button on the remote control to turn the display on or off.
Input Selection
To select USB playback, press the left navigation button.
To select DISC playback, press the right navigation button.
Playback Control
Press the button on the remote control to start and pause playback.
Press and hold the button on the remote control to stop playback and return to the start.
Toggle Standby Operation
Menu Navigation
Center button to select or play mode (random/repeat)
during playback
Left = Play from USB storage
Right = Play from CD tray
Amp Volume Control (ARCAM amps only)
Amp Mute On or Off (ARCAM amps only)
Display Brightness
Transport Keys – Play/Pause (long press to stop), skip
back/forward
Menu button
Music info button

Arcam CD5 Specifications

General

Type	CD Player
Output Level	2.2V RMS
Power Consumption	15W
Total Harmonic Distortion	0.002%
Digital Outputs	Coaxial, Optical
Signal to Noise Ratio	110dB (A-weighted)
Outputs	Stereo RCA
