7-8
4. Test drive the ATV on a dry, level surface and note
any pulling to the left or right during acceleration,
deceleration, and braking.
NOTE: If pulling is noted, measure the circumfer-
ence of the front and rear tires on the pulling side.
Compare the measurements with the tires on the
opposite side. If pulling is noted during braking
only, check and adjust the brakes as necessary
and recheck operation (see Section 2).
5. Increase the air pressure in the tires with the small-
est circumference measurement until all tires are
equal in circumference.
6. Repeat steps 4-5 as necessary to ensure proper
handling.
Troubleshooting
Problem: Suspension too soft
Condition Remedy
1. Spring(s) weak
2. Shock absorber damaged
3. Shock absorber preload too low
1. Replace spring(s)
2. Replace shock absorber
3. Adjust shock absorber preload
Problem: Suspension too stiff
Condition Remedy
1. A-arm-related bushings worn
2. Shock absorber preload too high
1. Replace bushing
2. Adjust shock absorber preload
Problem: Suspension noisy
Condition Remedy
1. Cap screws (suspension system) loose
2. A-arm-related bushings worn
1. Tighten cap screws
2. Replace bushings
Problem: Rear wheel oscillation
Condition Remedy
1. Rear wheel hub bearings worn - loose
2. Tires defective - incorrect
3. Wheel rim distorted
4. Wheel hub cap screws loose
5. Axle shaft nut loose (manual transmission)
6. Auxiliary brake adjusted incorrectly
7. Rear suspension arm-related bushing worn
8. Rear shock absorber damaged
9. Rear suspension arm nut loose
1. Replace bearings
2. Replace tires
3. Replace rim
4. Tighten cap screws
5. Tighten nut (manual transmission)
6. Adjust brake
7. Replace bushing
8. Replace shock absorber
9. Tighten nut
