23
DIVISION II - OPERATION/
MAINTENANCE
Division II - Operation/Maintenance
Specifications
Specifications subject to change without notice.
ENGINE AND DRIVE
Typ e
Four-Cycle/Liquid Cooled/OHC
Bore x Stroke 102 mm x 85 mm (4.01 x 3.35 in.)
Displacement
695 cc (42.4 cu in.)
Spark Plug Type
NGK CPR8E
Spark Plug Gap
0.7-0.8 mm (0.028-0.032 in.)
Brake Type
Hydraulic/mechanical parking and emergency w/brake lever lock
CHASSIS
Length (Overall)
218.0 cm (85.8 in.) - FIS
239.0 cm (94.1 in.) - TRV
Height (Overall)
129 cm (50.8 in.)
Width (Overall)
124 cm (48.8 in.)
Suspension Travel
25.4 cm (10 in.)
Tire Size (Front)
25 x 8R-12
Tire Size (Rear)
25 x 10R-12
Tire Inflation Pressure
34.5 kPa (5.0 psi)
MISCELLANY
Unladen Mass (Approx)
323 kg (712 lb) - FIS
365 kg (805 lb) - TRV
Gas Tank Capacity
21.6 L (5.7 U.S. gal.) - FIS
20.1 L (5.3 U.S. gal.) - TRV
Coolant Capacity 2.9 L (3.0 U.S. qt)
Differential Capacity
275 ml (9.3 fl oz)
Rear Drive Capacity
250 ml (8.5 fl oz)
Engine Oil Capacity 2.5 L (2.6 U.S. qt)
Gasoline (Recommended)
EU Unleaded 91 Octane
Engine Oil (Recommended)
Arctic Cat ACX All Weather (Synthetic)
Front Differential/Rear Drive
Lubricant
SAE Approved 80W-90 Hypoid
Taillight/Brakelight
12V/5W/21W
Headlight
12V/35W/35W
License Plate Light
12V/5W
Turn Signal - Front
12V/27W
Turn Signal - Rear
12V/10W
Position Light - Front
12V/5W
Starting System
Electric
