Arduino® GIGA R1 WiFi

15 / 21 Arduino® GIGA R1 WiFi Modiﬁed: 01/03/2023

14.3 Digital

Pin Function Type Description

1 D21/SCL1 Digital GPIO 21/I2C 1 Clock

2 D20/SDA1 Digital GPIO 20/I2C 1 Dataline

3 AREF Digital Analog Reference Voltage

4 GND Power Ground

5 D13/SCK Digital GPIO 13/SPI Clock

6 D12/CIPO Digital GPIO 12/SPI Controller In Peripheral Out

7 D11/COPI Digital GPIO 11/SPI Controller Out Peripheral In

8 D10/CS Digital GPIO 10/SPI Chip Select

9 D9/SDA2 Digital GPIO 9/I2C 2 Dataline

10 D8/SCL2 Digital GPIO 8/I2C 2 Clockline

11 D7 Digital GPIO 7

12 D6 Digital GPIO 6

13 D5 Digital GPIO 5

14 D4 Digital GPIO 4

15 D3 Digital GPIO 3

16 D2 Digital GPIO 2

17 D1/TX0 Digital GPIO 1 / Serial 0 Transmitter

18 D0/TX0 Digital GPIO 0 / Serial 0 Receiver

19 D14/TX3 Digital GPIO 14 / Serial 3 Transmitter

20 D15/RX3 Digital GPIO 15 / Serial 3 Receiver

21 D16/TX2 Digital GPIO 16 / Serial 2 Transmitter

22 D17/RX2 Digital GPIO 17 / Serial 2 Receiver

23 D18/TX1 Digital GPIO 18 / Serial 1 Transmitter

24 D19/RX1 Digital GPIO 19 / Serial 1 Receiver

25 D20/SDA Digital GPIO 20 / I2C 0 Dataline

26 D21/SCL Digital GPIO 21 / I2C 0 Clock
