Arduino® GIGA R1 WiFi

16 / 21 Arduino® GIGA R1 WiFi Modiﬁed: 01/03/2023

14.4 STM32 ICSP

Pin Function Type Description

1 CIPO Internal Controller In Peripheral Out

2 +5V Internal Power Supply of 5V

3 SCK Internal Serial Clock

4 COPI Internal Controller Out Peripheral In

5 RESET Internal Reset

6 GND Internal Ground

14.5 Digital Pins D22 - D53 LHS

Pin Function Type Description

1 +5V Power +5V Power Rail

2 D22 Digital GPIO 22

3 D24 Digital GPIO 24

4 D26 Digital GPIO 26

5 D28 Digital GPIO 28

6 D30 Digital GPIO 30

7 D32 Digital GPIO 32

8 D34 Digital GPIO 34

9 D36 Digital GPIO 36

10 D38 Digital GPIO 38

11 D40 Digital GPIO 40

12 D42 Digital GPIO 42

13 D44 Digital GPIO 44

14 D46 Digital GPIO 46

15 D48 Digital GPIO 48

16 D50 Digital GPIO 50

17 D52 Digital GPIO 52

18 GND Power Ground
