Arduino® GIGA R1 WiFi
3 / 21 Arduino® GIGA R1 WiFi Modified: 01/03/2023
USB
USB Host USB 2.0 Type A
Host
USB Peripheral USB-C®
Programming Port
HID
Connectors
Camera: 20 pin Arducam camera connector
Display: D1N, D0N, D1P, D0P, CKN, CKP, D68-D75
Audio jack: DAC0, DAC1, A7
JTAG connector
Power
Circuit operating voltage: 3.3V
Input voltage (VIN): 6-24V
DC Current per I/O Pin: 8 mA

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Arduino GIGA R1 WiFi and is the answer not in the manual?

Arduino GIGA R1 WiFi Specifications

General IconGeneral
Operating Voltage3.3V
Input Voltage (recommended)7-12V
Input Voltage (limit)6-24V
Digital I/O Pins76
PWM Pins12
Analog Input Pins12
Analog Output Pins2
Flash Memory2MB
SRAM1MB
DC Current per I/O Pin8 mA
MicrocontrollerSTM32H747XI
Wi-FiYes
BluetoothBluetooth 5.1
USBUSB-C
CommunicationUART, SPI, I2C, CAN
Clock Speed480 MHz
