1 Features
The MKR Vidor 4000 is nothing less than a powerhouse of a board, packing a huge set of features into a small form
factor. It features the Intel® Cyclone® 10CL016 for FPGA (Field Programming Gate Array), allowing you to configure
a large set of pins to accommodate any of your preferences. But why stop there? The board also has a camera
connector, a Micro HDMI connector, Wi-Fi® / Bluetooth® connectivity through the NINA-W102 module, and cyber-
security through the ECC508 crypto chip. Just like the other members of the MKR family, it uses the popular Arm®
Cortex®-M0 32-bit SAMD21 microprocessor.
1.1 Microcontroller Block
The board's microcontroller is a low power Arm® Cortex®-M0 32-bit SAMD21, like in the other boards within the
Arduino MKR family. The Wi-Fi® and Bluetooth® connectivity is performed with a module from u-blox, the NINA-
W10, a low power chipset operating in the 2.4GHz range. On top of that, secure communication is ensured through
the Microchip® ECC508 crypto chip. Also, you can find a battery charger, and a directionable RGB LED on-board.
Component Details
Microcontroller SAMD21 Arm® Cortex®-M0+ 32bit low power ARM MCU
USB connector Micro USB (USB-B)
Pins
Built-in LED Pin Pin 6
Digital I/O Pins x8
Analog Input Pins x7 (ADC 8/10/12 bit)
Analog Output Pins x1 (DAC 10 bit)
PMW Pins x13 (0 - 8, 10, 12, A3, A4)
External interrupts x10 (Pin 0, 1, 4, 5, 6, 7, 8,9, A1, A2)
Connectivity
Bluetooth® Nina W102 u-blox® module
Wi-Fi® Nina W102 u-blox® module
Secure element ATECC508A
Communication
UART Yes
I2C Yes
SPI Yes
Power
I/O Voltage 3.3 V
Input Voltage (nominal) 5-7 V
DC Current per I/O pin 7 mA
Supported battery Li-Po Single Cell, 3.7 V, 1024 mAh Minimum
Battery connector JST PH
Clock speed
Processor 48 MHz
RTC 32.768 kHz
Memory
SAMD21G18A 256 kB Flash, 32 kB SRAM
Nina W102 u-blox® module 448 kB ROM, 520 kB SRAM, 2 MB Flash
