Arduino® Nano 33 IoT
14 / 18 Arduino® Nano 33 IoT / Rev. 01 - 06/12/2021
6.2 Connector Positions
The view below is from top however it shows Debug connector pads which are on the bottom side. Highlighted
pins are pin 1 for each connector’
Top view:
Top side connectors
Bottom view:
Bottom side connectors
