Arduino®NanoRP2040Connect
Arduino®NanoRP2040Connect/Rev.01-03/05/202110/20
FrontViewofArduinoNanoRP2040ConnectTopology
Ref. Description Ref. Description
U1 RaspberryPiRP2040Microcontroller U2
UbloxNINA-W102-00B
WiFi/BluetoothModule
U3 N/A U4 ATECC608A-MAHDA-TCryptoIC
U5 AT25SF128A-MHB-T16MBFlashIC U6
MP2322GQHStep-DownBuck
Regulator
U7
DSC6111HI2B-012.0000MEMS
Oscillator
U8
MP34DT06JTRMEMS
OmnidirectionalMicrophoneIC
U9
LSM6DSOXTR6-axisIMUwithMachine
LearningCore
J1 MaleMicroUSBConnector
DL1 GreenPowerOnLED DL2 BuiltinOrangeLED
DL3 RGBCommonAnodeLED PB1 ResetButton
JP2 AnalogPin+D13Pins JP3 DigitalPins
7.2BackView
