Arduino®NanoRP2040Connect

Arduino®NanoRP2040Connect/Rev.01-03/05/202111/20

BackViewofArduinoNanoRP2040ConnectTopology

Ref. Description Ref. Description

SJ4 3.3Vjumper(connected) SJ1 VUSBjumper(disconnected)

8Processor

TheprocessorisbaseduponthenewRaspberryPiRP2040silicon(U1).Thismicrocontroller

providesopportunitiesforlow-powerInternetofThings(IoT)developmentandembedded

machinelearning.TwosymmetricArm®Cortex®-M0+clockedat133MHzprovide

computationpowerforembeddedmachinelearningandparallelprocessingwithlowpower

consumption.Sixindependantbanksof264KBSRAMand2MBareprovided.Directmemory

accessprovidesfastinterconnectbetweentheprocessorsandthememorythatcanbe

madeinactivealongwiththecoretoenterasleepstate.Serialwiredebug(SWD)is

avaliablefrombootviathepadsundertheboard.TheRP2040runsat3.3Vandhasan

internalvoltageregulatorproviding1.1V.

TheRP2040controlstheperipheralsanddigitalpins,aswellasanalogpins(A0-A3).TheI2C

connectionsonpinsA4(SDA)andA5(SCL)areusedforconnectingtotheonboards

peripheralsandarepulledupwitha4.7kΩresistor.SWDClockline(SWCLK)andresetare

alsopulledupwitha4.7kΩresistor.AnexternalMEMSoscillator(U7)runningat12MHz

providestheclockpulse.ProgrammbleIOhelpstotheimplementationofarbitary

communicationprotocolwithminimalburdenonthemainprocessingcores.AUSB1.1

deviceinterfaceisimplementedontheRP2040foruploadingcode.
