Arduino Nano RP2040 Connect User Manual

Arduino®NanoRP2040Connect
Arduino®NanoRP2040Connect/Rev.01-03/05/20215/20
7
7
7
7
8
8
9
9
10
11
12
12
12
12
12
13
13
14
14
14
14
14
14
15
15
15
16
16
16
17
1
18
18
Contents
1Applicationexamples
2Accessories
3Relatedproducts
4Recommendedoperatingconditions
5Powerconsumption
6BlockDiagram
7BoardTopology
7.1FrontView
7.2BackView
8Processor
9WiFi/Bluetoothconnectivity
106-axisIMU
11Externalmemory
12Cryptography
13Microphone
14RGBLED
15PowerTree
16BoardOperation
16.1Gettingstarted-IDE
16.2Gettingstarted-ArduinoWebEditor
16.3Gettingstarted-ArduinoIoTCloud
16.4SampleSketches
16.5Onlineresources
16.6BoardRecovery
17J1MicroUSB
18JP1
19JP2
20RP2040SWDPad
21NinaW102SWDPad
22DeclarationofConformityCEDoC(EU)
23DeclarationofConformitytoEURoHS&REACH21101/19/2021
24ConflictMineralsDeclaration
25FCCCaution

Arduino Nano RP2040 Connect Specifications

General

Microcontroller	Raspberry Pi RP2040
Flash Memory	16 MB
SRAM	264 KB
Clock Speed	133 MHz
Digital I/O Pins	20
Analog Input Pins	8
PWM Pins	20
UART	2
SPI	1
I2C	1
Operating Voltage	3.3V
Wireless and Bluetooth	u-blox NINA-W102
Microphone	Yes
Analog Output Pins	0
External Interrupts	All digital pins
Weight	5 g
WiFi	802.11b/g/n
USB	Micro USB
IMU	6-axis
Dimensions	45 mm x 18 mm
Bluetooth	Yes (u-blox NINA-W102)
