Arduino® Portenta H7 Lite Connected
10 / 20 Arduino® Portenta H7 Lite Connected Modified: 11/05/2022
High density connectors pinouts
Pin Description Pin Description
ETH
High Density
Connector
CAN
High Density
Connector
USB
High Density
Connector
DSI
High Density
Connector
CAM
High Density
Connector
DMIC
High Density
Connector
I2C0 I2C1 I2C2I2S
High Density
Connector
VSYS VIN V-SDCARDVCC VBUS USB ADC-
VREF
Power
GND Ground PWM
High Density
Connector

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Arduino Portenta H7 Series and is the answer not in the manual?

Arduino Portenta H7 Series Specifications

General IconGeneral
ProcessorDual-core Arm Cortex-M7 and Cortex-M4
Clock Speed480 MHz (Cortex-M7), 240 MHz (Cortex-M4)
Flash Memory2 MB
SRAM1 MB
Operating Voltage3.3V
Input Voltage (recommended)5V
EEPROMNo
Operating Temperature-40°C to +85°C
Dimensions66.04 mm x 25.4 mm
RAM8 MB SDRAM
Analog Output Pins2
ConnectivityWiFi, Bluetooth, Ethernet
WiFi802.11 b/g/n
BluetoothBluetooth 5
USBUSB 2.0
Ethernet10/100 Ethernet
Camera InterfaceParallel camera interface
CANYes
SPIYes
I2CYes
UARTYes
